Charging Cart TB Series

The TA Series is our first-generation model and one of our most durable. Built with thickened metal and a smooth finish, it features basic switches and ports for an intuitive, plug-and-play experience without complex operations.

CHARGING
UV Lamp
Timed Charging
drawer
TB Series Product Parameters

Stable Output
5-Layer Industrial Protection

USB-A 5V 2.4A output with integrated over-current, voltage, temperature, short-circuit, and grounding protection.

Charging

Charging complete / Standby

Make every use
clean and hygienic

The UV lamp disinfects each mobile phone, 30 seconds eliminates 99.99% of bacteria, avoids cross infection, and gives users clean and hygienic equipment.

Timing function

Set your charging time and disinfection time to protect the health of your device battery and prevent overcharging; uv one-click disinfection for 5 minutes;

It can also be devices storage locker

Internal Pull-Out Drawer Design: The built-in drawer can be easily pulled out for convenient access. Equipped with removable dividers, you can adjust the spacing freely to accommodate different devices of various sizes.

Comparison

QP-R10TB QP-R20TB QP-R30TB QP-R40TB QP-R52TB QP-R60TB QP-R65TB
Device capacity 10 20 30 40 52 60 65
Layout 1*10 2*10 3*10 4*10 4*13 5*12 5*13
Port USB USB USB USB USB USB USB
Input 220V/110V 220V/110V 220V/110V 220V/110V 220V/110V 220V/110V 220V/110V
Output 5V/2.4A 5V/2.4A 5V/2.4A 5V/2.4A 5V/2.4A 5V/2.4A 5V/2.4A
Power 200W 300W 400W 600W 600W 800W 800W
Slot size 310*27.5*212mm 310*27.5*212mm 310*27.5*212mm 310*27.5*212mm 310*27.5*212mm 310*30*212mm 310*27.5*212mm
Product size 540*390*330mm 556*400*665mm 556*400*920mm 556*400*1195mm 650*400*1195mm 650*400*1450mm 650*400*1450mm
Shipping size 610*470*410mm 630*470*735mm 630*470*990mm 630*470*1260mm 725*470*1260mm 720*470*1510mm 720*470*1510mm
G.W. 15kg 31kg 44kg 52kg 59kg 72kg 73kg
N.W. 19kg 37kg 52kg 60kg 70kg 83kg 84kg
Wheel size / 2" 2" 2.5" 2.5" 2.5" 2.5"
